Flexible PCB Printed Multilayer Circuit Board Double Side / Single Side

Good quality Flexible Membrane Switch for sales
Good quality Flexible Membrane Switch for sales
Competitive price, high quality goods with fast delivery schedule

—— Michael

A reliable membrane switch partner. With strong engineering team, and best service.

—— John

Very good quality membrane switch supplier.

—— Jenny

I'm Online Chat Now

Flexible PCB Printed Multilayer Circuit Board Double Side / Single Side

China Flexible PCB Printed Multilayer Circuit Board Double Side / Single Side supplier
Flexible PCB Printed Multilayer Circuit Board Double Side / Single Side supplier Flexible PCB Printed Multilayer Circuit Board Double Side / Single Side supplier Flexible PCB Printed Multilayer Circuit Board Double Side / Single Side supplier Flexible PCB Printed Multilayer Circuit Board Double Side / Single Side supplier

Large Image :  Flexible PCB Printed Multilayer Circuit Board Double Side / Single Side

Product Details:

Place of Origin: China
Brand Name: TKM MS
Certification: ISO9001:2008, SGS,Rohs
Model Number: HC

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: negotiation
Packaging Details: Polybag per pcs,50per cartoon
Delivery Time: 15-20days
Payment Terms: L/C, T/T
Supply Ability: 1000000Pieces per month
Contact Now
Detailed Product Description
Material: PCB Size: Customized Size
Type: Flexible Sample Time: 3-6 Working Days
Usage: All Specification: Rohs



Flexible Print PCB Double Side Single Side Multilayer Circuit Board





Multilayer Circuit Board Performance Index:





1.Electronic characteristics

Circuit rating 35V (DC), 100mA, 1W
Contact resistance 10Ω~500Ω (According the trace length and materials)
Insulation resistance > 100MΩ 250V DC
Contact bounce ≤ 5ms
Dielectric withstand 250VRms (50~60Hz 1min)
Life expectancy flat type ≥ 5 million times, tactile type ≥ 1 million times



2.Mechanical Properties

Actuation force flat type: 57-284g (2-10 Oz), tactile type: 170~397g (6~14 Oz)
Switch stroke flat type: 0.1~0.5mm, tactile type: 0.6~1.5mm



3.Environmental parameters

Operating Temperature -40°C~+80°C
Storage temperature -40°C~+85°C
Humidity 40°C, 90% ~95%, 240 hours




Flexible PCB Printed Multilayer Circuit Board Double Side / Single Side



Feature:


1. high quality and low price
2. long durability and lifecycle
3. strong ability of Anti electrostatic interference performance
4. metal dome could provide good tactile
The keys of the graphic overlay are embossed, the metal dome is embedded in the circuit layer, and there is a retainer
covering the metal dome. The appearance of this kind of membrane switch is stereoscopic. When you press the keys,
there is a strong tactile feeling and the time of the keys snap-back is very short. There is no need for the operator to judge
whether the switch is turned on by the sound signal or indicator lights given by the machine.





Applications:



1. The mobile phone

Focuses on the flexible circuit board light weight and thin thickness. Can effectively save the volume of products, easy connection of the battery, microphone, and buttons and into one.



2. Computer and LCD screen

Use the one line configuration of flexible circuit boards, and thin thickness. The digital signal into the picture, through the LCD screen



3. CD player

Focuses on three dimensional assembly characteristics of flexible circuit boards and thin thickness. The huge CD to carry around



4. Disk drives

Regardless of the hard disk, or diskette, is very dependent on FPC high softness and thickness of the 0.1 mm slim, read data finish quickly. Either a PC or NOTEBOOK.



5. The latest applications

Hard disk drives (HDDS, hard disk drive) of suspended circuit (Su ensi. N cireuit) and the components of xe packaging board, etc





Our advantage



1. 10 years' producing history and 10 years' exporting experience.

2. Professional engineering team will offer technical support in development step

of new project.

3. Provide one-stop production and assembly service from custom membrane

switch to PCBA, enclosure, back plate etc.

4. Using high standard mould to assure the products with high quality and precise

dimensions.

5. In-house 100% functionally tested.





Properties:


Operating voltage: < 35V DC
Operating current: < 100mA
Contact resistance: < 100 Ohms
Open circuit resistance: > 10M Ohms
Operating temperature: -35 to 70 degrees Celsius
Storage temperature: -45 to 90 degrees Celsius
Life expectancy: 500,000 to 30,000,000 cycles
Switch stroke: 0.1 to 0.6mm
Contact bounce: 5 to 30ms
Actuation force tolerance: +/- 20 to 45g
Tactile ratio: FC > 40%
Operating humidity: up to 95% RH





Customize Membrane Switch


FLEXKYS provides the service of customizing various membrane switch, such as intergrading components into complex, custom user-interface assemblies.We can mount
your switch panel to a rigidbacker, housing, casing, or to additional printed circuit board assemblies.
We will do what we can to help you.





we manufacture complete line of membrane switches, our experienced
Design team are ready to work with you to design membrane switches to meet
Your unique needs of your project
.

Contact Details
TaiKeMing (Dongguan) Membrane Products Technology Ltd.

Contact Person: katy

Send your inquiry directly to us (0 / 3000)
