Printed Circuit Tactile LED Membrane Switch With Embossing Key Rosh

Printed Circuit Tactile LED Membrane Switch With Embossing Key Rosh





Quick Detail:



Type FPC Operating Voltage ≤50(V)
Rated Current 0-30V DC Contact resistance 0.5-10( Ω)
Insulation Resistance ≤50(Ω) Key operation force 15-750g
Dome springback time ≤5(ms) Substrate voltage 1500VDC
High life time >1million times Operating Temperature

-20—60(C°)







Description:

FPC membrane switch is the circuit is not an ordinary silver line, but high temperature & corrosion of FPC line

Flat Printing Circuit
1) Custom made FPC
2) Rasing available
3) Membrane switch circuit
4) Withstand millions of cycles

5) Medical Equipment/Telecommunications apparatus/Telephone systems/Household appliances/Security systems/Point of sale apparatus/Industrial controls/Access control systems







Specifications





Material Copper Film
Adhesive 3M9448, 3M9080, 3M467, 3M468 or no adhesive
Tail with mylar or UV

Tail flexiblility any angle within 180 degree
Thickness above 0.7mm
Pressing lifespan more than 800,000 times
Metal dome Nicomatic, nickel plated, gold plated
Contact Bounce 5ms
keys embossed, rim embossed,or flat
Switch travel Flat Type 0.05-0.3mm
LED windows: clear or translucent with all colors


Membrane switches with FPC circuit:
Nice appearance and good tightness
Material: Autotype PET, textured PC, Gloss PC with matte finish, PVC
Connector: Nicomatic, FCI, Molex, Zif connector,CJT
Customized designs are accepted







Applications:



Products are widely used in communication, industrial control, household

appliances, GPS, children's kid-learning, electronic reading machine, various game machines, Instruments and Apparatuses, attendance machine,

Electronic scale, medical equipment, electronic tools equipment, automatic sewing machine,

Embroidery Machine, Machine Maintenance equipment, computer keyboard and electronic calculators and etc.

Remote control, control board for home appliances, medical equipment , auto, computer and cell phone, etc.





Competitive Advantage:



1. Beautiful appearance,rich and bright in color,design can be arbitrary,the products can fully reflect the individual style of the product itself and designer.

2. Panel can wash,good protection of durable color,characters,logos and other panel contents without injury.

3. Small size,light weight ,thin thickness,good tactility,abrasion resistant,installation and connection convenience.

4. Tightness is good ,moisture-proof,dust-proof,waterproof,anti-oil,anti-corrosion and erosion of harmful gases proof,acid and alkali proof,quakeproof.

5. Low cost,high lifespan,membrane switch's design and manufacture are using the keyboard as a whole way,whether on the material or mold charges,the costs are lowest,the life expectancy of different types of membrane switch is more than 100million times.

6. Easy to operate,intuitive,safe and reliable,In-house 100% functionally tested,components are guaranteed without any intermittent problem.

7. Customized specification is available and keys can make different shapes
