PCB Membrane Switch with Pocket Design and Inserts ≤100mA

A Printed Circuit Board Membrane Keyboard, also known as an Electronic PCB Switch, is a versatile and reliable input device that offers a seamless interface for various electronic applications. One of the key components of this innovative technology is the PCB Membrane Switch, which is designed to provide a responsive and efficient control mechanism.

The PCB Membrane Switch features a variety of attributes that enhance its functionality and usability. One such attribute is the Connector Tail options available for this product. The PCB Membrane Switch can be equipped with ZIF (Zero Insertion Force), Female Connector, or Male Connector tails, providing flexibility in connecting the switch to other electronic components.

Another notable feature is the option for a Black Keyboard, with the additional choice of a White Keyboard for those who prefer a different color scheme. The Black Keyboard option adds a sleek and modern look to the device, while the White Keyboard provides a bright and clean aesthetic.

Top Embossing is an additional feature that can be incorporated into the design. This enhances the tactile feedback of the switch, making it easier for users to locate and press the keys with precision.

The PCB Membrane Switch features a Pocket Design with Inserts. This design element allows for the incorporation of inserts within the switch, providing customization options for specific functions or key layouts.

• Product Name: PCB Membrane Switch
• Top Embossing: YES/NO
• Current: ≤100mA/Other
• Application: Agricultural Machine
• Circuit Rating: 35V (DC), 100mA, 1W
• Current Contact: 2-24V

The TKM PCB Membrane Switch combines the functionality of an Integrated Membrane Circuit Switch with the durability of a PCB construction, making it ideal for a wide range of applications including industrial machinery, medical devices, and consumer electronics.

With its ISO9001 certification and IP67 rating, this product is designed to withstand various environmental conditions, making it suitable for both indoor and outdoor use. The switch's low contact resistance (≤100Ω) ensures stable electrical connections across its 2-24V current range.

The silkscreen printing capability allows for custom labels, symbols, and graphics to meet specific application requirements, enhancing both functionality and professional appearance.
