2-Layer Flexible Printed Circuit Board with 150°C Max Temperature
-
Highlight
2-layer flexible circuit board
,high temperature flexible PCB
-
FeaturesWaterproof
-
Layer Count2 Layers
-
Max. Operating Temperature150°C
-
Dome Retainer0.05mmPET
-
Min. Hole Size0.2mm
-
Thickness0.1mm-0.3mm
-
Copper Thickness0.5oz-3oz
-
Rated Current50V
-
Place of OriginDongguan China
-
Brand Nametkm
2-Layer Flexible Printed Circuit Board with 150°C Max Temperature
2-Layer Flexible Printed Circuit Board with 150°C Max Temperature
Product Specifications
| Attribute | Value |
|---|---|
| Layer Count | 2 Layers |
| Max. Operating Temperature | 150°C |
| Dome Retainer | 0.05mm PET |
| Min. Hole Size | 0.2mm |
| Thickness | 0.1mm-0.3mm |
| Features | Waterproof |
| Copper Thickness | 0.5oz-3oz |
| Rated Current | 50V |
Product Overview
This Flex Circuit Board is a highly flexible printed circuit solution that can be bent or curved to fit various electronic devices. Constructed with durable polyimide material, it offers excellent heat resistance and mechanical properties for demanding applications.
The 2-layer design provides optimal balance between flexibility and functionality, allowing for more complex circuit designs while maintaining bendability. The board features a 0.05mm PET dome retainer for component protection and dimensional stability during flexing.
With a slim 0.2mm thickness profile and secured by 3M adhesive, this flexible circuit board is ideal for space-constrained applications requiring reliable performance under bending conditions.
Key Features
- Flexible printed circuit board with 2-layer construction
- 0.2mm board thickness for space-saving applications
- 0.2mm minimum hole size for precise component mounting
- 0.05mm PET dome retainer for enhanced protection
- Waterproof design for increased durability
- 2-layer configuration for improved circuit routing
Technical Parameters
| Adhesive | 3M |
| Max. Operating Temperature | 150°C |
| Board Thickness | 0.2mm |
| Raw Material | Polyimide |
| Connector | Female Pin |
| Shape | Custom Design |
| Max. Panel Size | 500mm × 500mm |
| Port | Shenzhen |
Applications
This flexible circuit board is ideal for:
- Wearable technology (smartwatches, fitness trackers)
- Flexible displays and curved electronic devices
- Automotive systems requiring vibration resistance
- Compact electronics with space constraints
- Applications demanding custom-shaped circuit boards
The board's custom design capability and 0.5oz-3oz copper thickness options make it adaptable to various current and heat requirements across multiple industries.
