Rigid flexible FPC circuit board
,Electric film switch membrane
,Flexible PCB with warranty
-
Model NO.HC-FPC-020
-
Combination ModeAdhesive Flexible Plate
-
Conductive AdhesiveConductive Silver Paste
-
Flame RetardantHB
-
Processing TechnologyElectrolytic Foil
-
Base MaterialCopper
-
Insulation MaterialsOrganic Resin
-
Size289.00mm * 216.00mm
-
Key Count136 Keys With Metal Dome And Embossing
-
Connector Type65pin (Zif)
-
LED Count12PCS
-
Wire Resistance≤ 1 Ohm/cm
-
Current Rating25-100mA, 0-30V DC
-
Work Voltage≤ 50V DC
-
Insulation Voltage≤ 100M Ohm 250V DC
-
Minimum Order Quantity100
Rigid Flexible Printing Electric FPC Circuit Board Film Switch
Rigid Flexible Printing Electric FPC Circuit Board Film Switch
We specialize in the production and processing of rigid flexible printed circuit board film switches with comprehensive system integrity and stable technical personnel. Our company provides complete one-stop service solutions for all your membrane switch requirements.
Layer Construction
- Overlay
- Overlay adhesive
- Dome retainer
- Metal dome
- Spacer adhesive
- Circuit
- Rear adhesive (customizable)
Production Capabilities
Our manufacturing facility includes comprehensive departments and equipment: Screen Print Department, IR Tunnel, Thickness Tester, IR Oven, Laser Cutting Machine, Punching Department, Emboss Key Section, Assembly, Electric Testing, OQC Department, Virtual Aspect Testing, Punch Machine Department, and PU Coating Section.
Technical Specifications
| Parameter | Specification |
|---|---|
| Wire Resistance | ≤ 1 Ohm/cm |
| Current Rating | 25-100mA, 0-30V DC |
| Work Voltage | ≤ 50V DC |
| Insulation Voltage | ≤ 100M Ohm 250V DC |
| Working Life | ≤ One Million Cycles |
| Work Temperature | -40°C to 70°C |
| Work Humidity | 40°C ≤ 98%RH |
| Basic Material Pressurization | 1500V DC |
