Electric Flexible Printed PCB Rigid Board Multilayer Circuit Board
-
Highlight
flexible printed circuit board multilayer
,electric rigid PCB board
,flexible membrane switch PCB
-
Model NO.HC-FPC-011
-
MaterialComplex
-
Flame RetardantV2
-
Mechanical RigidFexible
-
Processing TechnologyElectrolytic Foil
-
Base MaterialAluminum
-
Insulation MaterialsOrganic Resin
-
Wire Resistance≤ 1 Ohm/cm
-
Current Rating25-100mA, 0-30V DC
-
Work Voltage≤ 50V DC
-
Insulation Voltage≤ 100M Ohm 250V DC
-
Working Life≤ One Million Times
-
Work Temperature-40 Centigrade-70 Centigrade
-
Work Humidity40 Centigrade-≤ 98%RH
-
Basic Material Pressurization1500V DC
-
Minimum Order Quantity100
Electric Flexible Printed PCB Rigid Board Multilayer Circuit Board
Electric Flexible Printed PCB Rigid Board Multilayer Circuit Board
We are a professional manufacturing company with comprehensive production systems and stable technical personnel. We provide complete one-stop service solutions for flexible printed circuit boards.
Layer Structure
- Overlay
- Overlay adhesive
- Dome retainer
- Metal dome
- Spacer adhesive
- Circuit
- Rear adhesive (customizable)
Production Capabilities
- Screen Print Department
- IR Tunnel
- Thickness Tester
- IR Oven
- Laser Cutting Machine
- Punching Department
- Emboss Key Section
- Assemble
- Electric Testing
- OQC Department
- Virtual Aspect Testing
- Punch Machine Department
- PU Coating Section
Technical Specifications
| Wire Resistance | ≤ 1 Ohm/cm |
| Current Rating | 25-100mA, 0-30V DC |
| Work Voltage | ≤ 50V DC |
| Insulation Voltage | ≤ 100M Ohm 250V DC |
| Working Life | ≤ One Million Cycles |
| Work Temperature | -40°C to 70°C |
| Work Humidity | 40°C ≤ 98%RH |
| Basic Material Pressurization | 1500V DC |
Detailed Performance Parameters
| Insulation Resistance | <100MΩ, 250V DC |
| Contact Resistance | <1Ω/cm |
| Operating Voltage | ≤ 50V DC |
| Working Current | 25-100mA, 0-30V DC |
| Reliability/Service Life | >1 million cycles |
| Operating Humidity | 40°C <98%RH |
| Spring Time | ≤ 5ms |
| Substrate Voltage | 2000V DC |
| Tail Flexibility | Any angle within 180 degrees |
| Switch Travel | Flat Type: 0.05-0.3mm, Tactile Type: 0.3-1.5mm |
